GP-641 is a GPON ONT which is suited for FTTx residential applications. It complies with the ITU-T G.984 standard,provides 2.488Gbps downlink & 1.244Gbps uplink bandwidth at network side, and provides four(4) GE port, one(1) FXS, one(1) USB 3.0 and Wi-Fi 6 AX3000 WLAN port at user side.
GP-641 is a GPON ONT which is suited for FTTx residential applications. It complies with the ITU-T G.984 standard,provides 2.488Gbps downlink & 1.244Gbps uplink bandwidth at network side, and provides four(4) GE port, one(1) FXS, one(1) USB 3.0 and Wi-Fi 6 AX3000 WLAN port at user side.
The device provides high performance Data, Voice and Video services for individual users, SOHO (small office or family office), small businesses, etc.
| General |
Product Model： GP-641 ONT Type： GPON HGU Uplink： GPON Downlink： 4*GE + 1*FXS + Wi-Fi 6 + 1*USB Flash： 256MB NAND Memory： 512MB DDR4 Operating Temperature： -5 to 45°C Storage Temperature： -20 to 70°C Operating Humidity： 5% to 95%，non-condensing Installation： Desktop & Wall-mounted Dimensions: 190mm*135mm*33mm Net Weight: 240g |
| PON |
PON Interface GPON Connector SC/UPC or SC/APC Data Rate Downlink: 2.488Gbps; Uplink: 1.244Gbps Standard Compliance: ITU-T G.984 Pout(Optical TransmitterPower): 0dBm~4dBm Psens(Optical Sensitivity): -28dBm~-8dBm |
| GE LAN |
Ethernet Interface: RJ45 connectors Standard Compliance: IEEE 802.3, 802.3u, 802.3ab Link:Half-duplex and full-duplex operations; 10/100/1000 BaseT auto-negotiation and manual configuration; MDI/MDIX auto detection Full duplex IEEE 802.3x flow control and half duplex back-pressure flow control |
| FXS |
VoIP Interface: RJ11 connectors |
| USB |
Interface: USB 3.0 |
| Power |
Max Power Consumption: 10 watts Power Options: Wall adapter Wall Adapter: 100-240VAC in, 50/60Hz 12VDC out, 1.5A |
| Indicators |
PWR / PON / LOS / Internet / USB / 2.4G / 5G / WPS / LAN / VOIP |
| Button |
Reset: Reset to factory default Wi-Fi: Turn on/off WLAN WPS: Push button to start WPS pairing LED: Turn on/off LED indicator Power switch: Push button power on or off |
